Description
This manual call point according to DIN 14655 is suitable for direct connection to 230 V systems. It is supplied in a lockable aluminium housing including a key.
The button consists of a changeover contact with an internal reset lever.
In addition to the standard lettering “RAUCHABZUG”, it is also available with special lettering.
Replacement material
- spare glass sheet RT-E
- spare aluminium key RT-S-A
- spare plastic key RT-S-K
Specifications
- Contact rating 1 A / 230 VAC
- Connection terminals for cables up to 1,5 mm²
- Ambient conditions
- - Temperature: -10 °C to +55 °C
- - Relative humidity: 20 % to 80 % (non-condensing)
- Dimensions (W x H x D): 125 mm x 125 mm x 35 mm
- Protection class IP43
Variants
- RT230-A-OR 230 VAC alarm point orange
- RT230-A-RT 230 VAC alarm point red
- RT230-A-GE 230 VAC alarm point yellow
- RT230-A-GR 230 VAC alarm point grey
- RT230-A-BL 230 VAC alarm point blue
